MR66 Moving Coil Meter

MR66 Moving Coil Meter | Ammeter, Voltmeter & Galvanometer for Physics Laboratories

The MR66 Moving Coil Meter by ELMO Agencies is a precision analog measuring instrument designed for accurate measurement of electrical current, voltage, and small current variations. Available as an Ammeter, Voltmeter, and Galvanometer, the MR66 series is widely used in schools, colleges, engineering institutes, technical laboratories, and research centres for practical electrical experiments and demonstrations.

Manufactured with a high-quality moving coil mechanism, the MR66 Meter provides accurate readings, excellent sensitivity, and reliable long-term performance. Its robust construction and easy-to-read scale make it an ideal instrument for educational and laboratory applications.

As a trusted scientific manufacturer in Ambala, ELMO Agencies supplies premium educational and laboratory equipment manufactured according to international quality standards.

What Is an MR66 Moving Coil Meter?

The MR66 Moving Coil Meter is an analog electrical measuring instrument based on the Permanent Magnet Moving Coil (PMMC) principle. It is designed to measure direct current (DC), voltage, or very small electrical currents depending on the selected model.

Its precision movement ensures accurate and stable readings, making it suitable for laboratory experiments and electrical testing.

Working Principle

The MR66 Meter operates on the Permanent Magnet Moving Coil (PMMC) principle.

When electric current flows through the moving coil:

• A magnetic field is produced around the coil.
• The interaction between the coil and the permanent magnet generates torque.
• The pointer moves proportionally across the calibrated scale.
• The deflection indicates the measured electrical quantity.

This mechanism provides high sensitivity and excellent measurement accuracy.

Available Measurement Ranges

Ammeter Ranges

Single Range

• 250 µA
• 300 µA
• 500 µA
• 1 mA
• 5 mA
• 10 mA
• 50 mA
• 100 mA
• 300 mA
• 500 mA
• 1 A
• 3 A
• 5 A
• 10 A

Dual Range

• 1 A / 5 A
• 2.5 A / 5 A
• 500 mA / 1 A

Triple Range

• 50 mA / 500 mA / 5 A

---

Voltmeter Ranges

Single Range

• 100 mV
• 150 mV
• 250 mV
• 500 mV
• 1 V
• 2 V
• 3 V
• 5 V
• 10 V
• 15 V
• 20 V
• 25 V
• 100 V
• 150 V
• 300 V

Dual Range

• 1 V / 5 V
• 2.5 V / 5 V

Triple Range

• 3 V / 15 V / 30 V

---

Galvanometer Ranges

Single Range

• 30–0–30
• 35–0–35
• 50–0–50

Product Specifications

• Product Name: MR66 Moving Coil Meter
• Type: Analog PMMC Meter
• Models Available: Ammeter, Voltmeter & Galvanometer
• Display: Analog Pointer Scale
• Measurement: DC Current, DC Voltage & Small Current Detection
• Application: Physics and Electrical Laboratory Experiments

Educational Applications of MR66 Moving Coil Meter

Current Measurement

Measure direct current accurately during electrical experiments.

Voltage Measurement

Determine DC voltage across electrical components and circuits.

Galvanometer Experiments

Detect and measure very small currents in sensitive electrical circuits.

Ohm’s Law Verification

Measure current and voltage for resistance calculations.

Electrical Circuit Analysis

Monitor circuit performance during practical experiments.

STEM Learning

Supports hands-on education in electricity, electronics, and instrumentation.

Key Features of MR66 Moving Coil Meter

• High-precision moving coil mechanism
• Accurate and stable analog readings
• Wide range of Ammeter, Voltmeter, and Galvanometer options
• Clear and easy-to-read scale
• Durable laboratory-grade construction
• Suitable for schools, colleges, and engineering laboratories
• Reliable long-term performance
• Supports curriculum-based electrical experiments

Benefits of MR66 Moving Coil Meter

• High measurement accuracy
• Excellent sensitivity for laboratory work
• Smooth pointer movement
• Durable and maintenance-friendly design
• Ideal for educational and technical applications
• Suitable for repeated laboratory use

Frequently Asked Questions (FAQ)

Q1: What is the MR66 Moving Coil Meter used for?

A: It is used for measuring DC current, voltage, and small electrical currents in laboratory experiments.

Q2: Which instruments are available in the MR66 series?

A: The MR66 series is available as an Ammeter, Voltmeter, and Galvanometer.

Q3: What is the working principle of the MR66 Meter?

A: It works on the Permanent Magnet Moving Coil (PMMC) principle.

Q4: Is it suitable for educational laboratories?

A: Yes, it is widely used in schools, colleges, engineering institutes, and research laboratories.

Q5: Are multiple measurement ranges available?

A: Yes, the MR66 Meter is available in various single, dual, and triple measurement ranges to suit different laboratory applications.

Q6: Who supplies MR66 Moving Coil Meters in India?

A: ELMO Agencies, a trusted scientific manufacturer in Ambala, supplies high-quality laboratory and educational equipment across India.

Why Choose ELMO Agencies?

• 🏭 Trusted scientific manufacturer in Ambala
• 🔬 Premium electrical and laboratory equipment
• 🎓 Preferred by schools, colleges, and engineering institutions
• 📦 Bulk orders and institutional supply available
• 🚚 Nationwide and international delivery support

Conclusion

The MR66 Moving Coil Meter by ELMO Agencies is a reliable and precision-engineered measuring instrument for electrical and physics laboratories. Available as an Ammeter, Voltmeter, and Galvanometer with multiple measurement ranges, it provides accurate readings and dependable performance for educational, technical, and research applications. ELMO Agencies proudly manufactures and supplies quality educational products using modern manufacturing techniques and strict quality control procedures. Each product is carefully designed by laboratory professionals and experienced engineers with durability, accuracy, and long-term performance in mind. Manufactured using premium-grade raw materials and according to international quality standards, our products are built to withstand regular use in demanding laboratory environments while maintaining reliable performance.
